R系列英制轴承

深沟球轴承,R系列英制球轴承,型号尺寸查询表



R系列英制深沟球轴承,英制轴承适用所有密封结构

轴承
型号
主要尺寸 推荐安装尺寸
d D B (最小) 轴承座
开式 闭式
mm inch mm inch inch mm inch mm mm inch mm inch mm inch
R3 4.763 0.1875 12.700 0.5000 3.970 0.1562 4.980 0.1960 0.15 0.006 6.350 0.2500 11.125 0.4380
R3A 4.763 0.1875 12.700 0.5000 4.980 0.1960 4.980 0.1960 0.15 0.006 6.350 0.2500 11.125 0.4380
R4 6.350 0.2500 15.875 0.6250 4.980 0.1960 4.980 0.1960 0.20 0.008 7.950 0.3130 14.300 0.5630
R4A 6.350 0.2500 19.050 0.7500 5.560 0.2188 7.140 0.2812 0.30 0.012 8.738 0.3440 16.662 0.6560
R6 9.525 0.3750 22.225 0.8750 5.560 0.2188 7.140 0.2812 0.30 0.012 11.913 0.4690 19.837 0.7810
R8 12.700 0.5000 28.575 1.1250 6.350 0.2500 7.940 0.3125 0.30 0.012 15.088 0.5940 26.187 1.0310
R8-7 11.113 0.4375 28.575 1.1250 6.350 0.2500 ... ... 0.30 0.012 ... ... ... ...
R10 15.875 0.6250 34.925 1.3750 7.140 0.2812 8.730 0.3438 0.60 0.024 19.050 0.7500 31.750 1.2500
R12 19.050 0.7500 41.275 1.6250 7.940 0.3125 11.110 0.4375 0.60 0.024 23.012 0.9060 37.313 1.4690
R14 22.225 0.8750 47.625 1.8750 9.525 0.3750 12.700 0.5000 0.79 0.031 26.187 1.0310 43.663 1.7190
R16 25.400 1.0000 50.800 2.0000 9.525 0.3750 12.700 0.5000 0.79 0.031 29.362 1.1560 46.838 1.8440
R18 28.575 1.1250 53.975 2.1250 9.525 0.3750 12.700 0.5000 0.79 0.031 32.537 1.2810 50.013 1.9690
R20 31.750 1.2500 57.150 2.2500 9.525 0.3750 12.700 0.5000 0.79 0.031 35.712 1.4060 53.188 2.0940
R22 34.925 1.3750 63.500 2.5000 11.113 0.4375 14.288 0.5625 0.79 0.031 38.887 1.5310 59.538 2.3440
R24 38.100 1.5000 66.675 2.6250 11.113 0.4375 ... ... 0.79 0.031 42.062 1.6560 62.713 2.4690

☆卡锐轴承保留修改表中技术规则和其它数据的权利。
